Carbon Steel Welding Wire for Electrode ER70S-6 Welding Wire Oem Service Suppliers

Carbon Steel Welding Wire for Electrode ER70S-6 Welding Wire Oem Service Suppliers

material : Carbon steel
diameter : 0.8-1.6mm
flux content : 80%Ar+20%CO2
model number : ER50-6
Product name : ER50-6 Welding Wires
Material : Alloy Steel
Application : construction machinery

Product Description:

ER70S-6 is suitable for robot welding of construction machinery, automobiles, steel

structures, pipelines, containers, and arc welding.

Characteristics and Advantages :

Chemical composition of the welding wire (mass fraction) %
Items	C	Mn	Si	S	P
Standard Value	0.06-0.15	1.4-1.85	0.8-1.75	≤0.035	≤0.025
Case of Value	0.073	1.49	0.88	0.011	0.01

Typical values for the mechanical properties of deposited metals
Items	Tensile Strength	Yield Strength Rel/Rp0.2 MPa	Elongation	Charpy V-notch impact energy
Items	Rm/MPa	Yield Strength Rel/Rp0.2 MPa	A/%	KV2(J)-30℃
Standard Value	≥480	≥400	≥22	≥27
Case of Value	565	460	30	88
